Volume pricing
- 1+ pcs$15.37
- 10+ pcs$14.50
- 100+ pcs$13.68
- 500+ pcs$12.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- JESD-609 Kodu
- e4
- Circuit
- SPDT
- Voltage Rated Ac
- 28V
- Terminal Material
- PHOSPHOR BRONZE
- Current Rating Amps
- 0.4VA AC/DC
- Actuator Type
- Square, Button
- Length Termination
- 0.295 inch
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-On
- Housing Material
- Polyamide
- Insulation Resistance
- 200000000Ohm
- Additional Feature
- Non Illuminated Cap
- Ambalaj
- Bulk
- Body Height
- 21.4884mm
- Fabrika Tedarik Süresi
- 13 Weeks
- Sealing
- EPOXY
- Color Actuatorcap
- Gray
- Montaj
- Panel, Snap in
- Seri
- LB
- Yayın Yılı
- 2011
- Actuator Travel
- 2.9972 mm
- Body Breadth
- 15.7988 mm
- Panel Cutout Dimensions
- Square - 16.20mm2
- Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Contact Plating
- Gold
- Dielectric Withstanding Voltage
- 1500VAC V
- Contact Resistance
- 0.1mOhm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 200,000 Cycles
- Terminal
- Solder
- Electricallife
- 100,000 Cycles
- Body Length Or Diameter
- 17.8054mm
- Montaj Tipi
- Panel Mount, Snap-In
- Tip
- Standard
- Power Rating
- 400mW
- Çalışma Sıcaklığı
- -25°C~70°C
- Voltage Rated Dc
- 28V
