Volume pricing
- 1+ pcs$16.08
- 10+ pcs$15.17
- 100+ pcs$14.31
- 500+ pcs$13.50
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Çalışma Sıcaklığı
- -25°C~70°C
- Ratings
- Dust Tight, IP65, Water Resistant
- Length Termination
- 0.295 inch
- Current Rating Amps
- 3A AC/DC
- Tip
- Standard
- Body Breadth
- 15.7988 mm
- Voltage Rated Dc
- 30V
- Ingress Protection
- IP65 - Dust Tight, Water Resistant
- Fabrika Tedarik Süresi
- 13 Weeks
- Parça Durumu
- Active
- Terminal Material
- PHOSPHOR BRONZE
- Bushing Length
- 0.472 inch
- Terminal
- Solder
- Mechanical Life
- 1,000,000 Cycles
- Contact Plating
- Silver
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Body Length Or Diameter
- 15.7988mm
- Flammability Rating
- UL94 V-0
- Switch Function
- On-Mom
- Akım Değeri
- 3A
- Contact Ac Max Rating R Load
- 3A@250VAC
- Montaj
- Front, Panel
- Contact Resistance
- 0.05mOhm
- Panel Cutout Dimensions
- Circular - 22.00mm Dia
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2011
- Actuator Type
- Plunger for Cap
- Insulation Resistance
- 200000000Ohm
- Kurşunsuz Kodu
- yes
- Contact Currentacmax
- 3A
- Sealing
- EPOXY
- Montaj Tipi
- Panel Mount, Front
- Electricallife
- 100,000 Cycles
- Actuator Length
- 0.197 inch
- Housing Material
- Polyamide
- RoHS Durumu
- ROHS3 Compliant
- Seri
- LB
- Contact Voltageacmax
- 250V
- Contact Function
- ON-(ON)
- Actuator Travel
- 2.9972 mm
