Volume pricing
- 1+ pcs$12.61
- 10+ pcs$11.89
- 100+ pcs$11.22
- 500+ pcs$10.58
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 30V
- Tip
- Standard
- Current Rating Amps
- 3A AC/DC
- Parça Durumu
- Active
- Terminal Material
- PHOSPHOR BRONZE
- Fabrika Tedarik Süresi
- 5 Weeks
- Onay Kuruluşu
- CSA, UL
- Kurşunsuz
- Contains Lead
- Max Voltage Rating Ac
- 250V
- Contact Timing
- BREAK-BEFORE-MAKE
- Çalışma Sıcaklığı
- -25°C~70°C
- Orientation
- Vertical
- Reach Svhc
- No SVHC
- Max Current Rating
- 3A
- Flammability Rating
- UL94 V-0
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Mechanical Life
- 1,000,000 Cycles
- Akım Değeri
- 3A
- Contact Materials
- Silver
- Switch Function
- On-Mom
- Terminal
- Solder
- Max Voltage Rating Dc
- 30V
- Insulation Resistance
- 200MOhm
- Actuator Type
- Plunger for Cap
- Kurşunsuz Kodu
- yes
- Montaj
- Panel, Snap in
- Yayın Yılı
- 2011
- Panel Cutout Dimensions
- Rectangular - 22.40mm x 16.20mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Resistance
- 0.05mOhm
- Contact Function
- ON-(ON)
- ECCN Kodu
- EAR99
- Seri
- LB
- Voltage Rated Ac
- 125V
- Number Of Poles
- 1
- Ambalaj
- Bulk
- Circuit
- SPDT
- Uzunluk
- 23.7mm
- Electricallife
- 100,000 Cycles
- Montaj Tipi
- Panel Mount, Snap-In
