Specifications
- Kılıf / Paket
- 125
- Illumination Color
- Red
- Max Voltage Rating Dc
- 30V
- Terminal Stili
- Solder Lug
- Circuit
- DPDT
- Orientation
- Vertical
- Akım Değeri
- 1A
- Illumination Type Color
- LED, Red
- Switch Function
- On-On
- Tip
- Standard, Illuminated
- Contact Materials
- Silver
- Actuator Type
- Square, Button
- Uzunluk
- 14mm
- Color Actuatorcap
- Clear (Red Filter/Diffuser)
- Depth
- 14mm
- Fabrika Tedarik Süresi
- 8 Weeks
- Current Rating Amps
- 1A AC/DC
- Flammability Rating
- UL94 V-0
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Illumination Voltage Nominal
- 1.9VDC
- Montaj
- Front, Panel
- Lens Color
- Clear
- Max Current Rating
- 1A
- Housing Material
- Polyamide
- Reach Svhc
- No SVHC
- Panel Cutout Dimensions
- Circular - 12.30mm Dia
- Voltage Rated Ac
- 125V
- Genişlik
- 14mm
- Voltage Rated Dc
- 30V
- Max Voltage Rating Ac
- 250V
- Mechanical Life
- 100,000 Cycles
- Çalışma Sıcaklığı
- -25°C~50°C
- Illumination Type
- LED
- Terminal
- Solder
- Yayın Yılı
- 2011
- Kurşunsuz
- Contains Lead
- Seri
- KB
- Ambalaj
- Bulk
