KB16CKW01-5F-JF

Specifications

Illumination Type Color

LED, Green

Parça Durumu

Obsolete

Electricallife

50,000 Cycles

Reach Svhc

No SVHC

Current Rating Amps

1A AC/DC

ECCN Kodu

EAR99

Voltage Rated Ac

125V

Illumination Type

LED

Max Voltage Rating Dc

30V

Tip

Standard, Illuminated

RoHS Durumu

ROHS3 Compliant

Max Voltage Rating Ac

250V

Seri

KB

Voltage Rated Dc

30V

Montaj Tipi

Panel Mount, Front

Kılıf / Paket

125

Mechanical Life

100,000 Cycles

Akım Değeri

1A

Nem Hassasiyeti (MSL)

1 (Unlimited)

Çap

14mm

Circuit

SPDT

Yayın Yılı

2011

Fabrika Tedarik Süresi

10 Weeks

Illumination Color

Green

Contact Materials

Silver

Panel Cutout Dimensions

Circular - 12.30mm Dia

Kurşunsuz Kodu

yes

Uzunluk

14mm

Montaj

Front, Panel

JESD-609 Kodu

e4

Illumination Voltage Nominal

2.1VDC

Contact Current Rating

1A

Housing Material

Polyamide

Switch Function

On-On

Çalışma Sıcaklığı

-25°C~50°C

Flammability Rating

UL94 V-0

Terminal Stili

Solder Lug

Orientation

Vertical

Ambalaj

Bulk

Lens Color

Clear
