Volume pricing
- 1+ pcs$3.87
- 10+ pcs$3.65
- 100+ pcs$3.45
- 500+ pcs$3.25
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- JESD-609 Kodu
- e4
- Illumination Type
- Illuminated, Non-Illuminated
- Terminal Stili
- PC Pin
- Montaj Tipi
- Through Hole
- Genişlik
- 17.7mm
- Actuator Type
- Square Button
- Circuit
- SPST-NO
- Contact Current Rating
- 50mA
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -25°C~85°C
- Parça Durumu
- Active
- Renk
- Grey
- Özellikler
- Process Sealed
- Illumination
- Non-Illuminated
- Terminal
- Solder
- Depth
- 17.7mm
- Contact Materials
- Brass, Bronze, Silver
- Number Of Poles
- 1
- Throw Configuration
- SPST
- Switch Function
- Off-Mom
- Pozisyon Sayısı
- 2
- Switch Type
- KEYPAD SWITCH
- Orientation
- Straight
- Akım Değeri
- 50mA
- Mechanical Life
- 500,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Voltage Rated Dc
- 24V
- Actuator Height Off Pcb Vertical
- 5.08mm
- Yayın Yılı
- 2006
- Montaj
- Through Hole
- Insulation Resistance
- 500MOhm
- Switch Travel
- 0.40mm
- Seri
- JF
- Fabrika Tedarik Süresi
- 9 Weeks
- Contact Rating Voltage
- 0.05A @ 24VDC
- Operating Force
- 300gf
- Reach Svhc
- No SVHC
- Max Current Rating
- 50mA
- Outline
- 17.70mm x 17.70mm
- Ambalaj
- Tray
