Volume pricing
- 1+ pcs$7.01
- 10+ pcs$6.62
- 100+ pcs$6.24
- 500+ pcs$5.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Through Hole
- Actuator Height Off Pcb Vertical
- 6.78mm
- Voltage Rated Dc
- 24V
- Yayın Yılı
- 2012
- Switch Travel
- 0.80mm
- Contact Rating Voltage
- 0.05A @ 24VDC
- Fabrika Tedarik Süresi
- 14 Weeks
- Seri
- JF
- Contact Function
- OFF-(ON)
- Actuator Orientation
- Top Actuated
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Washability
- SOLVENT
- Terminal Material
- BRASS
- Actuatorcolor
- BLUE
- Montaj Tipi
- Through Hole
- JESD-609 Kodu
- e4
- Dielectric Withstanding Voltage
- 250VAC V
- Body Breadth
- 17.7038 mm
- Circuit
- SPST-NO
- Actuator Type
- Square Button
- Özellikler
- Process Sealed
- Parça Durumu
- Active
- Throw Configuration
- SPST
- Illumination
- Illuminated
- Body Height
- 5.715mm
- Illumination Type Color
- LED, Red
- Mechanical Life
- 500,000 Cycles
- Akım Değeri
- 50mA
- Length Termination
- 0.236 inch
- Switch Type
- KEYPAD SWITCH
- Solderability
- WAVE
- Body Length Or Diameter
- 22.7838mm
- End Contact Material
- BRASS
- Contact Resistance
- 0.05mOhm
- Insulation Resistance
- 500000000Ohm
- Operating Force
- 200gf
- Pcb Hole Count
- 6
- Contact Plating
- Silver
- Actuator Material
- Polyamide (PA), Nylon
