Volume pricing
- 1+ pcs$7.03
- 10+ pcs$6.63
- 100+ pcs$6.26
- 500+ pcs$5.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Tray
- Contact Dc Max Rating R Load
- 0.05A@24VDC
- Outline
- 22.80mm x 17.70mm
- ECCN Kodu
- EAR99
- Contact Plating
- Silver
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Actuator Material
- Polyamide (PA), Nylon
- Pcb Hole Count
- 6
- Operating Force
- 200gf
- Max Current Rating
- 50mA
- Contact Resistance
- 0.05mOhm
- Insulation Resistance
- 500000000Ohm
- Solderability
- WAVE
- Orientation
- Straight
- Switch Type
- KEYPAD SWITCH
- Illumination Type Color
- LED, Red
- Mechanical Life
- 500,000 Cycles
- Akım Değeri
- 50mA
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Terminal
- PC Pin
- Electricallife
- 500000 Cycle(s)
- Depth
- 17.7mm
- Contact Materials
- Bronze
- Illumination Voltage Nominal
- 1.7VDC
- Switch Function
- Off-Mom
- Çalışma Sıcaklığı
- -25°C~70°C
- Kurşunsuz
- Lead Free
- Illumination Type
- Illuminated, LED
- Number Of Switches
- 1
- Terminal Stili
- PC Pin
- Additional Feature
- RECT. HSNG.&SCULPTRD., RED LED
- Contact Currentdcmax
- 0.05A
- Washability
- SOLVENT
- Actuatorcolor
- RED
- Terminal Material
- BRASS
- Actuator Orientation
- Top Actuated
- Uzunluk
- 22.8mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- JF
- Contact Function
- OFF-(ON)
