Volume pricing
- 1+ pcs$5.68
- 10+ pcs$5.36
- 100+ pcs$5.05
- 500+ pcs$4.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Body Length Or Diameter
- 22.7838mm
- Solderability
- WAVE
- Insulation Resistance
- 500000000Ohm
- Contact Resistance
- 0.05mOhm
- End Contact Material
- BRASS
- Length Termination
- 0.236 inch
- Illumination Type Color
- LED, Red
- Mechanical Life
- 500,000 Cycles
- Akım Değeri
- 50mA
- Switch Type
- KEYPAD SWITCH
- Actuator Material
- Polyamide (PA), Nylon
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Contact Plating
- Silver
- Outline
- 22.80mm x 17.70mm
- Contact Dc Max Rating R Load
- 0.05A@24VDC
- Ambalaj
- Box
- Operating Force
- 300gf
- Pcb Hole Count
- 6
- Center Contact Material
- PHOSPHOR BRONZE
- Contact Currentdcmax
- 0.05A
- Terminal Stili
- PC Pin
- Additional Feature
- RECT. HSNG.&RD. ACTU., RED LED
- Illumination Type
- Illuminated, LED
- Number Of Switches
- 1
- Switch Function
- Off-Mom
- Illumination Voltage Nominal
- 1.7VDC
- Electricallife
- 500000 Cycle(s)
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Terminal
- PC Pin
- Çalışma Sıcaklığı
- -25°C~70°C
- Switch Travel
- 0.40mm
- Yayın Yılı
- 2012
- Voltage Rated Dc
- 24V
- Actuator Height Off Pcb Vertical
- 5.08mm
- Montaj
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Orientation
- Top Actuated
- Actuatorcolor
- GREEN
- Terminal Material
- BRASS
