Volume pricing
- 1+ pcs$3.63
- 10+ pcs$3.42
- 100+ pcs$3.23
- 500+ pcs$3.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Illumination Type
- Illuminated, Non-Illuminated
- Number Of Switches
- 1
- Contact Currentdcmax
- 0.05A
- Terminal Stili
- PC Pin
- Additional Feature
- ROUND HOUSING & ACTUATOR
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -25°C~85°C
- Electricallife
- 500000 Cycle(s)
- Depth
- 17.7mm
- Contact Materials
- Brass
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Terminal
- PC Pins
- Switch Function
- Off-Mom
- Orientation
- Straight
- Switch Type
- KEYPAD SWITCH
- Mechanical Life
- 500,000 Cycles
- Akım Değeri
- 50mA
- Insulation Resistance
- 500000000Ohm
- Contact Resistance
- 0.05mOhm
- Solderability
- WAVE
- Pcb Hole Count
- 4
- Max Current Rating
- 50mA
- Operating Force
- 300gf
- ECCN Kodu
- EAR99
- Outline
- 17.70mm Dia
- Contact Dc Max Rating R Load
- 0.05A@24VDC
- Ambalaj
- Tray
- Actuator Material
- Polyamide (PA), Nylon
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Contact Plating
- Silver
- Dielectric Withstanding Voltage
- 250VAC V
- JESD-609 Kodu
- e4
- Montaj Tipi
- Through Hole
- Contact Current Rating
- 50mA
- Actuator Type
- Round Button
- HTS Kodu
- 8536.50.90.40
- Circuit
- SPST-NO
- Parça Durumu
- Active
- Renk
- Green
- Özellikler
- Process Sealed
