Volume pricing
- 1+ pcs$3.40
- 10+ pcs$3.21
- 100+ pcs$3.02
- 500+ pcs$2.85
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Illumination Type
- Illuminated, Non-Illuminated
- Number Of Switches
- 1
- Terminal Stili
- PC Pin
- Additional Feature
- ROUND HOUSING & ACTUATOR
- Contact Currentdcmax
- 0.05A
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Terminal
- Solder
- Depth
- 17.7mm
- Electricallife
- 500000 Cycle(s)
- Contact Materials
- Brass, Bronze, Silver
- Number Of Poles
- 1
- Pozisyon Sayısı
- 2
- Switch Function
- Off-Mom
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Resistance
- 0.05mOhm
- Insulation Resistance
- 500MOhm
- Solderability
- WAVE
- Orientation
- Straight
- Switch Type
- KEYPAD SWITCH
- Mechanical Life
- 500,000 Cycles
- Akım Değeri
- 50mA
- Outline
- 17.70mm Dia
- Ambalaj
- Tray
- ECCN Kodu
- EAR99
- Contact Plating
- Silver
- Actuator Material
- Polyamide (PA), Nylon
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Yükseklik
- 8.68mm
- Pcb Hole Count
- 4
- Operating Force
- 300gf
- Max Current Rating
- 50mA
- Actuator Type
- Round Button
- HTS Kodu
- 8536.50.90.40
- Circuit
- SPST-NO
- Contact Current Rating
- 50mA
- JESD-609 Kodu
- e4
- Montaj Tipi
- Through Hole
- Genişlik
- 17.7mm
- Illumination
- Non-Illuminated
