Volume pricing
- 1+ pcs$8.59
- 10+ pcs$8.11
- 100+ pcs$7.65
- 500+ pcs$7.22
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Illumination Type Color
- LED, Green
- Mechanical Life
- 500,000 Cycles
- Akım Değeri
- 50mA
- Orientation
- Straight
- Solderability
- WAVE
- Insulation Resistance
- 500000000Ohm
- Contact Resistance
- 0.05mOhm
- Max Current Rating
- 50mA
- Operating Force
- 300gf
- Pcb Hole Count
- 6
- Insulation Materials
- GLASS FILLED POLYESTER
- Actuator Material
- Polycarbonate (PC)
- Contact Plating
- Silver
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Contact Dc Max Rating R Load
- 0.05A@24VDC
- Outline
- 22.80mm x 17.70mm
- Contact Currentdcmax
- 0.05A
- Terminal Stili
- PC Pin
- Illumination Type
- Illuminated, LED
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -25°C~70°C
- Switch Function
- Off-Mom
- Illumination Voltage Nominal
- 2.3VDC
- Electricallife
- 500000 Cycle(s)
- Depth
- 17.7mm
- Contact Materials
- Bronze
- Housing Material
- GLASS FILLED POLYAMIDE
- Terminal
- PC Pin
- Yayın Yılı
- 2011
- Actuator Height Off Pcb Vertical
- 6.70mm
- Voltage Rated Dc
- 24V
- Montaj
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Switch Travel
- 0.40mm
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 14 Weeks
- Contact Rating Voltage
- 0.05A @ 24VDC
- Contact Function
- OFF-(ON)
- Seri
- JF
