Volume pricing
- 1+ pcs$3.84
- 10+ pcs$3.62
- 100+ pcs$3.41
- 500+ pcs$3.22
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Çalışma Sıcaklığı
- -25°C~70°C
- Terminal Stili
- PC Pin
- Outline
- 10.00mm x 10.00mm
- Contact Plating
- Silver
- Max Current Rating
- 50mA
- Illumination Type Color
- LED, Yellow
- Depth
- 12mm
- Actuator Orientation
- Top Actuated
- Illumination
- Illuminated
- Mechanical Life
- 5,000,000 Cycles
- Illumination Voltage Nominal
- 2VDC
- Terminal
- PC Pin
- Actuator Type
- Plunger for Cap
- Actuator Travel
- 0.254 mm
- Kurşunsuz
- Lead Free
- RoHS Durumu
- ROHS3 Compliant
- Pcb Hole Count
- 4
- Contact Dc Max Rating R Load
- 0.05A@24VDC
- Body Height
- 4.9022mm
- Özellikler
- Process Sealed
- Sealing
- EPOXY
- Actuator Length
- 6.3mm
- Seri
- JB
- Solderability
- WAVE
- Switch Function
- Off-Mom
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Kurşunsuz Kodu
- yes
- Ambalaj
- Tray
- Terminal Material
- BRASS
- Max Voltage Rating Dc
- 24V
- Electricallife
- 5e+06 cycles
- Montaj
- Through Hole
- Operating Force
- 176gf
- Voltage Rated Dc
- 24V
- Throw Configuration
- SPST
- Insulation Resistance
- 500000000Ohm
- Switch Travel
- 0.25mm
- Montaj Tipi
- Through Hole
- Illumination Type
- Illuminated, LED
- Contact Currentdcmax
- 0.05A
