Volume pricing
- 1+ pcs$3.33
- 10+ pcs$3.14
- 100+ pcs$2.97
- 500+ pcs$2.80
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuator Type
- Square Button
- Kurşunsuz
- Lead Free
- Pcb Hole Count
- 4
- RoHS Durumu
- ROHS3 Compliant
- Contact Dc Max Rating R Load
- 0.125A@24VDC
- Body Height
- 4.191mm
- Özellikler
- Process Sealed
- Mechanical Life
- 1,000,000 Cycles
- Terminal
- PC Pin
- Seri
- JB
- Solderability
- WAVE
- Switch Function
- Off-Mom
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Kurşunsuz Kodu
- yes
- Switch Type
- KEYPAD SWITCH
- Ambalaj
- Tray
- JESD-609 Kodu
- e4
- Terminal Stili
- PC Pin
- HTS Kodu
- 8536.50.90.40
- Ratings
- Dust Tight, IP67, Waterproof
- Outline
- 10.00mm x 10.00mm
- Çalışma Sıcaklığı
- -25°C~70°C
- Illumination
- Non-Illuminated
- Additional Feature
- FLAT CAP
- Max Current Rating
- 125mA
- Contact Plating
- Silver
- Depth
- 11.8mm
- Actuator Orientation
- Top Actuated
- Actuator Height Off Pcb Vertical
- 14.70mm
- ECCN Kodu
- EAR99
- Contact Resistance
- 0.05mOhm
- Yayın Yılı
- 2012
- Reach Svhc
- No SVHC
- Dielectric Withstanding Voltage
- 250VAC V
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Materials
- Stainless Steel
- Akım Değeri
- 125mA
- Contact Current Rating
- 125mA
- Contact Function
- OFF-(ON)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
