Volume pricing
- 1+ pcs$3.30
- 10+ pcs$3.12
- 100+ pcs$2.94
- 500+ pcs$2.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Material
- BRASS
- Electricallife
- 1000000 Cycle(s)
- Renk
- Grey
- Operating Force
- 265gf
- Montaj
- Through Hole
- Voltage Rated Dc
- 24V
- Throw Configuration
- SPST
- Insulation Resistance
- 500000000Ohm
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Switch Travel
- 0.30mm
- Number Of Switches
- 1
- Montaj Tipi
- Through Hole
- Contact Currentdcmax
- 0.125A
- Parça Durumu
- Active
- Length Termination
- 0.122 inch
- Dielectric Withstanding Voltage
- 250VAC V
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Resistance
- 0.05mOhm
- Yayın Yılı
- 2012
- Contact Function
- OFF-(ON)
- Contact Rating Voltage
- 0.125A @ 24VDC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 9 Weeks
- Circuit
- SPST-NO
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Body Breadth
- 10.0076 mm
- Akım Değeri
- 125mA
- Çalışma Sıcaklığı
- -25°C~70°C
- Terminal Stili
- PC Pin
- Outline
- 10.00mm x 10.00mm
- Ratings
- Dust Tight, IP67, Waterproof
- Contact Plating
- Silver
- Actuator Height Off Pcb Vertical
- 14.70mm
- Actuator Orientation
- Top Actuated
- Center Contact Material
- BERYLLIUM COPPER
- Illumination
- Non-Illuminated
- Additional Feature
- SCULPTURED CAP
- Terminal
- PC Pin
- Mechanical Life
- 1,000,000 Cycles
- Actuator Type
- Square Button
