Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Sealing
- EPOXY
- Face Size
- 23.13mm Lx20.59mm W
- ECCN Kodu
- EAR99
- Led Forward Voltage
- 2.2 3.3VDC
- RoHS Durumu
- ROHS3 Compliant
- Display Type
- LCD
- Contact Current Rating
- 100mA
- Contact Currentdcmax
- 0.1A
- Kurşunsuz Kodu
- yes
- Pixel Format
- 36 x 24
- Insulation Resistance
- 100000000Ohm
- Contact Dc Max Rating R Load
- 0.1A@12VDC
- Illumination
- LED
- Contact Rating Voltage
- 0.1A @ 12VDC
- Seri
- SmartDisplay™
- Terminal
- PC Pin
- Contact Function
- OFF-(ON)
- Viewing Area Height
- 17mm
- Travel Range
- 1.8mm
- Montaj
- Through Hole
- Terminal Stili
- PC Pin
- Throw Configuration
- SPST
- Çalışma Sıcaklığı
- -20°C~60°C
- Viewing Area
- 17.0mm L x 13.0mm W
- Display Mode
- Black and White, FSTN Positive
- Montaj Tipi
- Through Hole
- Electricallife
- 3000000 Cycle(s)
- Yayın Yılı
- 2013
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Function
- Off-Mom
- Tip
- Pushbutton, LCD
- Circuit
- SPST-NO
- Style
- Standard
- Actuator Travel
- 4.4958 mm
- Contact Resistance
- 0.2mOhm
- Renk
- Green, Red
- Operating Force
- 173gf
- Fabrika Tedarik Süresi
- 15 Weeks
- Viewing Area Width
- 13mm
- Led Forward Current
- 15 15mA
