Specifications
- Max Voltage Rating Ac
- 250V
- Switch Type
- ROTARY SWITCH
- Current Rating Amps
- 6A AC 5A DC
- Number Of Poles
- 1
- Contact Materials
- Phosphor Bronze
- Contact Style
- Non-Shorting
- Contact Timing
- Non-Shorting (BBM)
- Actuator Length
- 10.00mm
- Contact Dc Max Rating R Load
- 5A@30VDC
- Depth
- 19.9898mm
- Depth Behind Panel
- 20.00mm
- Contact Currentdcmax
- 5A
- Seri
- HS
- Actuator Material
- Brass
- Insulation Resistance
- 200MOhm
- Max Voltage Rating Dc
- 30V
- Actuator Type
- Round (6mm Dia)
- Parça Durumu
- Obsolete
- Electricallife
- 7500 Cycle(s)
- Bushing Length
- 0.394 inch
- End Contact Plating
- SILVER
- Min. Çalışma Sıcaklığı
- -10°C
- Actuator Finish
- NICKEL
- Montaj Tipi
- Panel Mount
- ECCN Kodu
- EAR99
- Circuit Per Deck
- SPDT
- Voltage Rated Ac
- 125V
- Terminal
- Solder
- Index Stops
- Fixed
- Terminal Stili
- Solder Lug
- Maks. Çalışma Sıcaklığı
- 70°C
- Solderability
- HAND
- Voltage Rated Dc
- 30V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Index Angle
- 45 °
- Insulation Materials
- PHENOLIC
- Fabrika Tedarik Süresi
- 8 Weeks
- Panel Cutout Dimensions
- Circular - 10.30mm Dia
- Orientation
- Vertical
- Contact Current Rating
- 3A
