Volume pricing
- 1+ pcs$1.13
- 10+ pcs$1.07
- 100+ pcs$1.01
- 500+ pcs$0.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 9 Weeks
- Mechanical Life
- 500,000 Cycles
- Voltage Rated Ac
- 28V
- RoHS Durumu
- ROHS3 Compliant
- Contact Plating
- Gold
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Contact Materials
- Stainless Steel
- Montaj Tipi
- Surface Mount
- Kurşunsuz
- Lead Free
- Switch Travel
- 0.20mm
- Switch Function
- Off-Mom
- Terminal Stili
- Gull Wing
- Özellikler
- Sealed - Flux Protection
- Actuator Type
- Standard
- Illumination
- Non-Illuminated
- Outline
- 6.20mm x 6.20mm
- Circuit
- SPST-NO
- Illumination Type
- Illuminated, Non-Illuminated
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- HP03
- Yayın Yılı
- 2012
- Parça Durumu
- Active
- Terminal
- Gull Wing
- Depth
- 6.2mm
- Montaj
- Surface Mount
- Operating Force
- 160gf
- Voltage Rated Dc
- 28V
- Kurşunsuz Kodu
- yes
- Max Current Rating
- 100mA
- Ambalaj
- Tape & Reel (TR)
- Switch Type
- KEYPAD SWITCH
- Throw Configuration
- SPST
- Contact Rating Voltage
- 0.4VA @ 28VAC/DC
- Contact Current Rating
- 100mA
- Reach Svhc
- No SVHC
- Orientation
- Straight
- Uzunluk
- 9mm
- Power Rating
- 3W
- Actuator Height Off Pcb Vertical
- 4.40mm
- Actuator Orientation
- Top Actuated
