Volume pricing
- 1+ pcs$10.68
- 10+ pcs$10.07
- 100+ pcs$9.50
- 500+ pcs$8.96
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mechanical Life
- 100,000 Cycles
- Insulation Resistance
- 100000000Ohm
- Circuit
- SPDT
- Contact Resistance
- 0.05mOhm
- Illumination Color
- Red
- Voltage Rated Ac
- 30V
- Power Rating
- 100mW
- Illumination Voltage Nominal
- 1.95VDC
- Contact Dc Max Rating R Load
- 0.1A@30VDC
- Akım Değeri
- 100mA
- Yayın Yılı
- 2012
- Ambalaj
- Tray
- Contact Ac Max Rating R Load
- 0.1A@30VAC
- Tip
- Standard, Illuminated
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 18 Weeks
- Terminal Stili
- Solder Lug
- Panel Cutout Dimensions
- Circular - 8.00mm Dia
- Contact Currentacmax
- 0.1A
- Kurşunsuz Kodu
- yes
- Orientation
- Vertical
- Contact Function
- ON-(ON)
- Terminal Material
- PHOSPHOR BRONZE
- Illumination Type Color
- LED, Red
- Length Termination
- 0.197 inch
- Contact Current Rating
- 100mA
- Housing Material
- Polyamide
- Current Rating Amps
- 100mA AC/DC
- Electricallife
- 50,000 Cycles
- Contact Plating
- Silver
- Illumination Type
- Illuminated, LED
- Center Contact Material
- PHOSPHOR BRONZE
- Voltage Rated Dc
- 30V
- Reach Svhc
- No SVHC
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Actuator Type
- Square, Button
- Dielectric Withstanding Voltage
- 500VAC V
- Çalışma Sıcaklığı
- -25°C~50°C
- Montaj
- Front, Panel
