Volume pricing
- 1+ pcs$12.66
- 10+ pcs$11.94
- 100+ pcs$11.27
- 500+ pcs$10.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Ac Max Rating R Load
- 0.1A@30VAC
- Yayın Yılı
- 2012
- Ambalaj
- Tray
- Akım Değeri
- 100mA
- Contact Dc Max Rating R Load
- 0.1A@30VDC
- Illumination Voltage Nominal
- 2.1VDC
- Contact Resistance
- 0.05mOhm
- Body Color
- BLACK
- Power Rating
- 100mW
- Voltage Rated Ac
- 30V
- Illumination Color
- Green
- Circuit
- SPDT
- Mechanical Life
- 100,000 Cycles
- Insulation Resistance
- 100000000Ohm
- Contact Function
- ON-(ON)
- Orientation
- Vertical
- Kurşunsuz Kodu
- yes
- Contact Currentacmax
- 0.1A
- Panel Cutout Dimensions
- Circular - 8.00mm Dia
- Terminal Stili
- Solder Lug
- Max Voltage Rating Dc
- 30V
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 5 Weeks
- Tip
- Standard, Illuminated
- Montaj
- Front, Panel
- Terminal
- Solder
- Çalışma Sıcaklığı
- -25°C~50°C
- Actuator Type
- Round, Button
- Dielectric Withstanding Voltage
- 500VAC V
- Reach Svhc
- No SVHC
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Voltage Rated Dc
- 30V
- Illumination Type
- Illuminated, LED
- Max Voltage Rating Ac
- 30V
- Contact Plating
- Silver
- Contact Materials
- Bronze
- Electricallife
- 50,000 Cycles
- Contact Current Rating
- 100mA
- Housing Material
- Polyamide
