Volume pricing
- 1+ pcs$10.73
- 10+ pcs$10.12
- 100+ pcs$9.55
- 500+ pcs$9.01
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuator Type
- Plunger for Cap
- Dielectric Withstanding Voltage
- 500VAC V
- Ambalaj
- Tray
- Çalışma Sıcaklığı
- -25°C~70°C
- Yayın Yılı
- 2012
- Terminal
- Solder
- Montaj
- Front, Panel
- HTS Kodu
- 8536.50.90.33
- Akım Değeri
- 100mA
- Voltage Rated Dc
- 30V
- Kurşunsuz
- Lead Free
- Pozisyon Sayısı
- 2
- ECCN Kodu
- EAR99
- Reach Svhc
- No SVHC
- Power Rating
- 100mW
- Voltage Rated Ac
- 30V
- Contact Resistance
- 0.05mOhm
- Insulation Resistance
- 100MOhm
- Current Rating Amps
- 100mA AC/DC
- Contact Current Rating
- 100mA
- Housing Material
- Polyamide
- Mechanical Life
- 100,000 Cycles
- Circuit
- SPDT
- Electricallife
- 50,000 Cycles
- Contact Materials
- Bronze, Silver
- Contact Plating
- Silver
- Orientation
- Vertical
- Contact Function
- ON-(ON)
- Terminal Material
- PHOSPHOR BRONZE
- RoHS Durumu
- ROHS3 Compliant
- Number Of Poles
- 1
- Panel Cutout Dimensions
- Circular - 8.00mm Dia
- REACH Uyumluluk Kodu
- unknown
- Onay Kuruluşu
- UL
- Kurşunsuz Kodu
- yes
- Seri
- HB
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Panel Mount, Front
- Terminal Stili
- Solder Lug
- Switch Function
- On-Mom
