Volume pricing
- 1+ pcs$4.24
- 10+ pcs$4.00
- 100+ pcs$3.77
- 500+ pcs$3.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 12.72mm
- Fabrika Tedarik Süresi
- 10 Weeks
- Current Rating Amps
- 0.4VA AC/DC
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide
- Max Current Rating
- 100mA
- Montaj
- Through Hole
- Contact Resistance
- 0.08mOhm
- Max Voltage Rating Dc
- 28V
- Terminal Stili
- PC Pin
- Actuator Angle
- 28 deg
- Circuit
- DPDT
- Orientation
- Right Angle
- Switch Function
- On-On
- Actuator Type
- Concave (Curved)
- Contact Materials
- Bronze
- Uzunluk
- 7.5mm
- Color Actuatorcap
- White
- Actuator Material
- Glass fibre, Polyamide
- Ambalaj
- Tray
- Parça Durumu
- Active
- Seri
- GW
- Özellikler
- Sealed - Flux Protection
- Montaj Tipi
- Through Hole, Right Angle
- Contact Plating
- Gold
- Sealing
- EPOXY
- Electricallife
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Actuator Marking
- No Marking
- Voltage Rated Ac
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- Max Voltage Rating Ac
- 28V
- Voltage Rated Dc
- 28V
- Çalışma Sıcaklığı
- -30°C~85°C
- Mechanical Life
- 50,000 Cycles
- Terminal
- PC Pin
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Yayın Yılı
- 2010
