Volume pricing
- 1+ pcs$3.44
- 10+ pcs$3.25
- 100+ pcs$3.06
- 500+ pcs$2.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Sealing
- EPOXY
- Contact Plating
- Gold
- Color Actuatorcap
- White
- Center Contact Material
- PHOSPHOR BRONZE
- Actuator Type
- Paddle
- Insulation Resistance
- 500000000Ohm
- Terminal Material
- PHOSPHOR BRONZE
- Actuator Angle
- 28 deg
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Kurşunsuz Kodu
- yes
- Voltage Rated Ac
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- Housing Material
- GLASS FILLED POLYAMIDE
- Length Termination
- 0.102 inch
- Mechanical Life
- 50,000 Cycles
- Voltage Rated Dc
- 28V
- Switch Function
- On-On
- Çalışma Sıcaklığı
- -30°C~85°C
- Orientation
- Right Angle
- Actuator Length
- 0.15 inch
- Parça Durumu
- Active
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Fabrika Tedarik Süresi
- 10 Weeks
- Terminal
- PC Pin
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Actuator Marking
- No Marking
- Ambalaj
- Tray
- Current Rating Amps
- 0.4VA AC/DC
- Özellikler
- Sealed - Flux Protection
- Montaj Tipi
- Through Hole, Right Angle
- Electricallife
- 50,000 Cycles
- JESD-609 Kodu
- e4
- Montaj
- Through Hole
- Circuit
- SPDT
- End Contact Material
- PHOSPHOR BRONZE
- Seri
- GW
- Actuator Material
- GLASS FILLED POLYAMIDE
- Terminal Stili
- PC Pin
