Volume pricing
- 1+ pcs$4.90
- 10+ pcs$4.63
- 100+ pcs$4.36
- 500+ pcs$4.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 28V
- Solderability
- WAVE
- Montaj Tipi
- Through Hole, Right Angle
- Mechanical Life
- 50,000 Cycles
- Throw Configuration
- SPST
- Electricallife
- 50,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- GB2
- Orientation
- Right Angle
- Contact Function
- OFF-(ON)
- Body Height
- 10.5156mm
- Reach Svhc
- No SVHC
- Ambalaj
- Tray
- Uzunluk
- 7.6mm
- Özellikler
- Epoxy Sealed Terminals
- Actuator Type
- Plunger for Cap
- ECCN Kodu
- EAR99
- JESD-609 Kodu
- e4
- Contact Current Rating
- 100mA
- Circuit
- SPST-NO x 2
- Terminal Stili
- PC Pin
- Tip
- Standard
- Max Current Rating
- 100mA
- Power Rating
- 400mW
- Çalışma Sıcaklığı
- -25°C~70°C
- Depth
- 13.97mm
- Terminal
- PC Pin
- Life Cycles
- 50000 cycles
- Max Voltage Rating Dc
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- Contact Resistance
- 0.08mOhm
- Pcb Hole Count
- 4
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Contact Plating
- Gold
- Body Breadth
- 5.7404 mm
- Max Voltage Rating Ac
- 28V
- Actuator Material
- Glass fibre, Polyamide
- Yayın Yılı
- 2010
- Color Actuatorcap
- Gray
