Volume pricing
- 1+ pcs$6.82
- 10+ pcs$6.43
- 100+ pcs$6.07
- 500+ pcs$5.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pcb Hole Count
- 5
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Resistance
- 0.08mOhm
- Dielectric Withstanding Voltage
- 500VAC V
- Max Voltage Rating Dc
- 28V
- Contact Plating
- Gold
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Body Breadth
- 4.9022 mm
- Max Voltage Rating Ac
- 28V
- Yayın Yılı
- 2015
- Actuator Material
- Polyacetal
- Terminal Stili
- PC Pin
- Depth
- 14.22mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Voltage Rated Dc
- 28V
- Tip
- Standard
- Max Current Rating
- 100mA
- Montaj Tipi
- Through Hole, Right Angle
- Solderability
- WAVE
- Mechanical Life
- 50,000 Cycles
- Terminal
- PC Pins
- Electricallife
- 50,000 Cycles
- Insulation Resistance
- 500000000Ohm
- Housing Material
- Polyamide
- Uzunluk
- 7.8mm
- Switch Function
- On-Mom
- RoHS Durumu
- ROHS3 Compliant
- Actuator Type
- Round, Button
- Current Rating Amps
- 0.4VA AC/DC
- Contact Materials
- Bronze
- JESD-609 Kodu
- e4
- ECCN Kodu
- EAR99
- Circuit
- SPDT
- Contact Current Rating
- 100mA
- Voltage Rated Ac
- 28V
- Seri
- GB
- Montaj
- Through Hole
- Color Actuatorcap
- Black
- Contact Function
- ON-(ON)
