Volume pricing
- 1+ pcs$5.02
- 10+ pcs$4.73
- 100+ pcs$4.46
- 500+ pcs$4.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal
- Solder
- Power Rating
- 400mW
- Çalışma Sıcaklığı
- -30°C~85°C
- Depth
- 14.22mm
- Tip
- Standard
- Max Current Rating
- 100mA
- Terminal Stili
- PC Pin
- Yayın Yılı
- 2012
- Actuator Material
- Polyacetal
- Switching Capacity
- 400 mW
- Body Breadth
- 4.9022 mm
- Max Voltage Rating Ac
- 28V
- Contact Plating
- Gold
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Pcb Hole Count
- 5
- Contact Resistance
- 0.08mOhm
- Dielectric Withstanding Voltage
- 500VAC V
- Max Voltage Rating Dc
- 28V
- Sealing
- EPOXY
- Fabrika Tedarik Süresi
- 9 Weeks
- Kurşunsuz
- Lead Free
- Color Actuatorcap
- White
- Montaj
- PCB, Through Hole
- Current Rating Amps
- 0.4VA AC/DC
- Contact Materials
- Bronze, Gold
- Voltage Rated Ac
- 28V
- Terminal Material
- PHOSPHOR BRONZE
- Housing Material
- Polyamide
- Insulation Resistance
- 500MOhm
- Additional Feature
- BLACK CAP
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-Mom
- Mechanical Life
- 50,000 Cycles
- Electricallife
- 50,000 Cycles
- Solderability
- WAVE
- Montaj Tipi
- Through Hole, Right Angle
- Voltage Rated Dc
- 28V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Tray
