Volume pricing
- 1+ pcs$6.90
- 10+ pcs$6.51
- 100+ pcs$6.14
- 500+ pcs$5.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım Değeri
- 100mA
- RoHS Durumu
- ROHS3 Compliant
- Contact Ac Max Rating R Load
- .014A@28VAC
- Pcb Hole Count
- 5
- Terminal
- Gull Wing
- Circuit
- SPDT
- Uzunluk
- 8.5mm
- Illumination Type
- Illuminated, Non-Illuminated
- Reach Svhc
- No SVHC
- Parça Durumu
- Active
- Voltage Rated Dc
- 28V
- Electricallife
- 50,000 Cycles
- Current Rating Amps
- 0.4VA AC/DC
- Sealing
- EPOXY TERMINAL SEALED
- HTS Kodu
- 8536.50.90.40
- Fabrika Tedarik Süresi
- 9 Weeks
- Çalışma Sıcaklığı
- -30°C~85°C
- Operating Forcemax
- 1.6 N
- Housing Material
- Resin
- Dielectric Withstanding Voltage
- 500VAC V
- Genişlik
- 8.5mm
- Terminal Stili
- Gull Wing
- Contact Materials
- Bronze
- Insulation Resistance
- 500MOhm
- Orientation
- Vertical
- Kurşunsuz
- Lead Free
- Switch Function
- On-Off-On
- Yayın Yılı
- 2006
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Montaj Tipi
- Surface Mount
- Yükseklik
- 9mm
- Contact Resistance
- 0.08mOhm
- Voltage Rated Ac
- 28V
- Actuator Material
- Polyphenylene Sulfide (PPS)
- Özellikler
- Process Sealed
- Montaj
- Surface Mount
- Switch Type
- TOGGLE SWITCH
- Max Current Rating
- 100mA
- Max Voltage Rating Ac
- 28V
