Volume pricing
- 1+ pcs$5.63
- 10+ pcs$5.31
- 100+ pcs$5.01
- 500+ pcs$4.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Current Rating
- 100mA
- Çalışma Sıcaklığı
- -25°C~85°C
- Orientation
- Vertical
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Process Sealed
- Voltage Rated Ac
- 28V
- Housing Material
- Polyamide
- Electricallife
- 100,000 Cycles
- Max Voltage Rating Ac
- 28V
- Contact Current Rating
- 100mA
- Current Rating Amps
- 0.4VA AC/DC
- Terminal Material
- PHOSPHOR BRONZE
- Max Voltage Rating Dc
- 28V
- Voltage Rated Dc
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- HTS Kodu
- 8536.50.90.65
- Fabrika Tedarik Süresi
- 5 Weeks
- Illumination
- Non-Illuminated
- Seri
- G
- JESD-609 Kodu
- e4
- Terminal Stili
- PC Pin
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole
- Circuit
- DPDT
- Body Breadth
- 4.4958 mm
- Kurşunsuz
- Lead Free
- Montaj
- PCB, Through Hole
- Yayın Yılı
- 2015
- Actuator Type
- Standard Round
- Contact Resistance
- 0.08mOhm
- Uzunluk
- 7mm
- ECCN Kodu
- EAR99
- Pcb Hole Count
- 6
- Actuator Length
- 3.80mm
- Contact Plating
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Bronze, Gold
- Bushing Thread
- Unthreaded
