Volume pricing
- 1+ pcs$5.64
- 10+ pcs$5.32
- 100+ pcs$5.02
- 500+ pcs$4.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- G
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2010
- Actuator Type
- Standard Round
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Özellikler
- Process Sealed
- Contact Function
- ON-OFF-(ON)
- Contact Plating
- Gold
- Washability
- SOLVENT
- Bushing Thread
- Unthreaded
- Illumination Type
- Illuminated, Non-Illuminated
- JESD-609 Kodu
- e4
- End Contact Material
- PHOSPHOR BRONZE
- HTS Kodu
- 8536.50.90.65
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Solderability
- WAVE
- Voltage Rated Dc
- 28V
- Sealing
- EPOXY
- Current Rating Amps
- 0.4VA AC/DC
- Contact Resistance
- 0.08mOhm
- Montaj
- Through Hole
- Orientation
- Vertical
- Body Length Or Diameter
- 7.0104mm
- Electricallife
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Circuit
- SPDT
- Center Contact Material
- PHOSPHOR BRONZE
- Actuator Length
- 3.80mm
- Contact Current Rating
- 100mA
- Body Breadth
- 4.4958 mm
- Terminal Stili
- PC Pin
- Switch Function
- On-Off-Mom
- Bushing Length
- 0.063 inch
- Montaj Tipi
- Through Hole
- Length Termination
- 0.102 inch
- Reach Svhc
- No SVHC
- Pcb Hole Count
- 5
- Terminal Material
- PHOSPHOR BRONZE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
