Specifications
- Kurşunsuz Kodu
- yes
- Center Contact Material
- PHOSPHOR BRONZE
- Fabrika Tedarik Süresi
- 8 Weeks
- Insulation Resistance
- 500000000Ohm
- Terminal
- PC Pin
- Yayın Yılı
- 2010
- Bushing Thread
- Unthreaded
- Terminal Stili
- PC Pin
- Özellikler
- Process Sealed
- Electricallife
- 50,000 Cycles
- Contact Function
- ON-(ON)
- End Contact Material
- PHOSPHOR BRONZE
- RoHS Durumu
- ROHS3 Compliant
- Length Termination
- 0.142 inch
- Sealing
- EPOXY
- Washability
- SOLVENT
- Pcb Hole Count
- 5
- Actuator Length
- 3.80mm
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Solderability
- WAVE
- Switch Function
- On-Mom
- Contact Resistance
- 0.08mOhm
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Seri
- G
- Voltage Rated Ac
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Bushing Length
- 0.063 inch
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Current Rating Amps
- 0.4VA AC/DC
- Circuit
- SPDT
- Terminal Material
- PHOSPHOR BRONZE
- Body Length Or Diameter
- 7.4168mm
- Çalışma Sıcaklığı
- -25°C~85°C
- JESD-609 Kodu
- e4
- Body Breadth
- 4.4958 mm
- Body Height
- 16.764mm
- Illumination
- Non-Illuminated
- Voltage Rated Dc
- 28V
