Specifications
- JESD-609 Kodu
- e4
- Akım Değeri
- 100mA
- Terminal
- PC Pins
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 9 Weeks
- Actuatorcolor
- ORANGE
- Pozisyon Sayısı
- 16
- Yayın Yılı
- 2009
- Body Material
- Polyamide (PA), Nylon, Glass Filled
- Seri
- FR01
- Body Height
- 6.5532mm
- Contact Timing
- BREAK-BEFORE-MAKE
- Material
- PVC
- Height Above Board
- 0.394 10.00mm
- Actuator Level
- Flush, Recessed
- Nominal Gerilim
- 5VDC
- Pcb Hole Count
- 3
- Contact Finish
- Gold
- Kurşunsuz Kodu
- yes
- Index Angle
- 22.5 deg
- Uzunluk
- 0.393 10.00mm
- RoHS Durumu
- ROHS3 Compliant
- Electricallife
- 10,000 Steps
- Actuator Type
- Rotary for Tool
- Mechanical Life
- 10,000 Steps
- Montaj
- PCB, Through Hole
- Reach Svhc
- No SVHC
- Terminal Stili
- PC Pin
- Throw Configuration
- SP16T
- Voltage Rated Dc
- 5V
- Orientation
- Right Angle
- Washable
- No
- Dielectric Withstanding Voltage
- 250VAC V
- Insulation Resistance
- 1GOhm
- Max Current Rating
- 100mA
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -25°C~85°C
- HTS Kodu
- 8536.50.90.20
- Contact Voltagedcmax
- 5V
- Kurşunsuz
- Lead Free
