Volume pricing
- 1+ pcs$8.38
- 10+ pcs$7.91
- 100+ pcs$7.46
- 500+ pcs$7.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Material
- COPPER
- Parça Durumu
- Active
- Body Breadth
- 10.9982 mm
- Actuator Travel
- 2.2098 mm
- Seri
- EB
- Voltage Rated Ac
- 125V
- Center Contact Material
- COPPER
- Terminal
- PC Pin
- Actuator Type
- Plunger for Cap
- Actuator Length
- 0.366 inch
- Akım Değeri
- 3A
- Contact Ac Max Rating R Load
- 3A@125VAC
- Dielectric Withstanding Voltage
- 1500VAC V
- ECCN Kodu
- EAR99
- Contact Resistance
- 0.01mOhm
- Kurşunsuz Kodu
- yes
- Housing Material
- Resin
- Bushing Length
- 0.268 inch
- Actuator Material
- BRASS
- REACH Uyumluluk Kodu
- not_compliant
- Montaj
- Bushing, Panel
- Tip
- Standard
- RoHS Durumu
- ROHS3 Compliant
- Pcb Hole Count
- 6
- Mechanical Life
- 100,000 Cycles
- Contact Currentacmax
- 3A
- Çalışma Sıcaklığı
- -10°C~70°C
- Switch Function
- On-On
- Terminal Stili
- PC Pin
- Life Cycles
- 25000 cycles
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 3A AC
- Length Termination
- 0.252 inch
- Yayın Yılı
- 2011
- Actuator Finish
- NICKEL
- Electricallife
- 25,000 Cycles
- Contact Plating
- Silver
- Body Height
- 15.2146mm
- Montaj Tipi
- Panel Mount, Rear
