Volume pricing
- 1+ pcs$10.22
- 10+ pcs$9.64
- 100+ pcs$9.09
- 500+ pcs$8.58
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 3A AC
- Insulation Resistance
- 1000000000Ohm
- Terminal Stili
- Solder Lug
- Çalışma Sıcaklığı
- -10°C~70°C
- Bushing Diameter
- 0.236 inch
- RoHS Durumu
- ROHS3 Compliant
- Mechanical Life
- 100,000 Cycles
- Ambalaj
- Bulk
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Orientation
- Vertical
- Actuator Finish
- NICKEL
- Electricallife
- 25,000 Cycles
- Yayın Yılı
- 2011
- Length Termination
- 0.157 inch
- Akım Değeri
- 3A
- Actuator Length
- 0.366 inch
- Center Contact Material
- COPPER
- Terminal
- Solder
- Actuator Type
- Plunger for Cap
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- REACH Uyumluluk Kodu
- not_compliant
- Bushing Length
- 0.268 inch
- Housing Material
- STAINLESS STEEL
- ECCN Kodu
- EAR99
- Dielectric Withstanding Voltage
- 1500VAC V
- Switch Function
- On-On
- Contact Currentacmax
- 3A
- Tip
- Standard
- Body Length Or Diameter
- 11.7094mm
- Özellikler
- Epoxy Sealed Terminals
- Circuit
- DPDT
- Fabrika Tedarik Süresi
- 5 Weeks
- Reach Svhc
- No SVHC
- Montaj Tipi
- Panel Mount, Rear
- Body Height
- 15.2146mm
- Contact Ac Max Rating R Load
- 3A@125VAC
- Voltage Rated Ac
- 125V
- Seri
- EB
- Actuator Travel
- 2.2098 mm
