Volume pricing
- 1+ pcs$6.57
- 10+ pcs$6.20
- 100+ pcs$5.85
- 500+ pcs$5.52
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Actuator Length
- 0.315 inch
- Akım Değeri
- 3A
- Terminal
- PC Pins
- Actuator Type
- Plunger for Cap
- ECCN Kodu
- EAR99
- Max Current Rating
- 3A
- Dielectric Withstanding Voltage
- 1500VAC V
- Housing Material
- STAINLESS STEEL
- Bushing Length
- 0.268 inch
- REACH Uyumluluk Kodu
- not_compliant
- Çalışma Sıcaklığı
- -10°C~70°C
- Bushing Diameter
- 0.236 inch
- RoHS Durumu
- ROHS3 Compliant
- Mechanical Life
- 100,000 Cycles
- Current Rating Amps
- 3A AC
- Insulation Resistance
- 1000000000Ohm
- Terminal Stili
- PC Pin
- Yayın Yılı
- 2011
- Electricallife
- 25,000 Cycles
- Actuator Finish
- CHROME
- Orientation
- Vertical
- Length Termination
- 0.252 inch
- Ambalaj
- Bulk
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Contact Current Rating
- 3A
- Body Breadth
- 10.9982 mm
- Contact Ac Max Rating R Load
- 3A@125VAC
- Seri
- EB
- Contact Function
- ON-(ON)
- Voltage Rated Ac
- 125V
- Contact Resistance
- 0.01mOhm
- Contact Materials
- Copper
- Kurşunsuz Kodu
- yes
- Montaj
- Panel
- Kurşunsuz
- Lead Free
- Actuator Material
- Brass
- Tip
- Standard
- Pcb Hole Count
- 6
