Volume pricing
- 1+ pcs$7.42
- 10+ pcs$7.00
- 100+ pcs$6.61
- 500+ pcs$6.23
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Switch Function
- On-Mom
- Contact Currentacmax
- 3A
- Color Actuatorcap
- White
- Tip
- Standard
- Body Length Or Diameter
- 11.7094mm
- Fabrika Tedarik Süresi
- 5 Weeks
- Circuit
- DPDT
- Özellikler
- Epoxy Sealed Terminals
- Montaj Tipi
- Panel Mount, Rear
- Body Height
- 15.2146mm
- Contact Plating
- Gold
- Contact Ac Max Rating R Load
- 3A@125VAC
- Flammability Rating
- UL94 V-0
- Voltage Rated Ac
- 125V
- Seri
- EB
- Contact Function
- ON-(ON)
- Actuator Travel
- 1.6002 mm
- Contact Current Rating
- 3A
- End Contact Material
- SILVER
- Body Breadth
- 10.9982 mm
- Terminal Material
- COPPER
- Montaj
- Panel, Snap in
- Actuator Material
- BRASS
- Kurşunsuz
- Contains Lead
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.01mOhm
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 3A AC
- Terminal Stili
- Solder Lug
- Bushing Diameter
- 0.236 inch
- Çalışma Sıcaklığı
- -10°C~70°C
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Ambalaj
- Bulk
- Orientation
- Vertical
- Electricallife
- 25,000 Cycles
- Actuator Finish
- CHROME
- Yayın Yılı
- 2007
- Length Termination
- 0.157 inch
