Volume pricing
- 1+ pcs$6.52
- 10+ pcs$6.15
- 100+ pcs$5.81
- 500+ pcs$5.48
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 3A AC
- Insulation Resistance
- 1000000000Ohm
- Terminal Stili
- PC Pin
- Bushing Diameter
- 0.236 inch
- Çalışma Sıcaklığı
- -10°C~70°C
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Ambalaj
- Bulk
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Actuator Finish
- CHROME
- Electricallife
- 25,000 Cycles
- Yayın Yılı
- 2011
- Orientation
- Vertical
- Sealing
- CORROSION PROOF; EPOXY TERMINAL SEALED
- Akım Değeri
- 3A
- Depth
- 8mm
- Actuator Type
- Plunger for Cap
- Terminal
- PC Pins
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- STAINLESS STEEL
- REACH Uyumluluk Kodu
- not_compliant
- ECCN Kodu
- EAR99
- Max Current Rating
- 3A
- Dielectric Withstanding Voltage
- 1500VAC V
- Uzunluk
- 11mm
- Switch Function
- On-Mom
- Operating Forcemax
- 2.35 N
- Contact Currentacmax
- 3A
- Pcb Hole Count
- 3
- Tip
- Standard
- Fabrika Tedarik Süresi
- 5 Weeks
- Circuit
- SPDT
- Özellikler
- Epoxy Sealed Terminals
- Max Voltage Rating Ac
- 125V
- Body Height
- 13.5mm
- Montaj Tipi
- Panel Mount, Rear
- Contact Plating
- Silver
- Contact Ac Max Rating R Load
- 3A@125VAC
- Voltage Rated Ac
- 125V
