Volume pricing
- 1+ pcs$6.97
- 10+ pcs$6.58
- 100+ pcs$6.21
- 500+ pcs$5.86
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- Solder Lug
- Voltage Rated Dc
- 28V
- Switch Function
- On-Mom
- Current Rating Amps
- 0.4VA AC/DC
- Insulation Resistance
- 1000000000Ohm
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Tip
- Standard
- Çalışma Sıcaklığı
- -10°C~70°C
- Contact Ac Max Power Rating R Load
- 0.4VA@28VAC
- Montaj Tipi
- Panel Mount, Rear
- Body Height
- 3.4036mm
- Ambalaj
- Bulk
- Body Length Or Diameter
- 10.9982mm
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 10 Weeks
- Özellikler
- Epoxy Sealed Terminals
- Length Termination
- 0.157 inch
- Center Contact Plating
- GOLD
- Orientation
- Vertical
- Electricallife
- 50,000 Cycles
- Yayın Yılı
- 2014
- Actuator Type
- Plunger for Cap
- Terminal
- Solder
- Voltage Rated Ac
- 28V
- Center Contact Material
- COPPER
- Contact Function
- ON-(ON)
- Seri
- EB
- Body Breadth
- 7.0104 mm
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Material
- COPPER
- End Contact Material
- SILVER
- REACH Uyumluluk Kodu
- not_compliant
- Actuator Material
- BRASS
- Kurşunsuz
- Contains Lead
- Montaj
- Panel
- End Contact Plating
- GOLD
- Kurşunsuz Kodu
- yes
