Volume pricing
- 1+ pcs$18.07
- 10+ pcs$17.04
- 100+ pcs$16.08
- 500+ pcs$15.17
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Ac
- 48V
- Illumination Type
- Illuminated, Non-Illuminated
- Center Contact Material
- PHOSPHOR BRONZE
- Akım Değeri
- 100mA
- Yayın Yılı
- 2015
- Ambalaj
- Bulk
- JESD-609 Kodu
- e4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Body Breadth
- 14.4018 mm
- Bushing Type
- M6P0.75
- Fabrika Tedarik Süresi
- 9 Weeks
- Dielectric Withstanding Voltage
- 1500VAC V
- Power Rating
- 400mW
- Bushing Thread
- M6 x 0.75
- Body Height
- 13.8938mm
- Montaj
- Panel
- Actuator Material
- Brass, Chrome Plated
- Contact Resistance
- 0.05mOhm
- Actuator Type
- Locking Lever
- Actuator Length
- 19.40mm
- Bushing Length
- 0.24 inch
- Terminal Stili
- PC Pin
- Seri
- D2
- Çalışma Sıcaklığı
- -10°C~70°C
- Housing Material
- POLYBUTYLENE TEREPHTHALATE
- Electricallife
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Insulation Resistance
- 1000000000Ohm
- Length Termination
- 0.142 inch
- Pcb Hole Count
- 12
- Parça Durumu
- Active
- Illumination
- Non-Illuminated
- Insulation Materials
- LIQUID CRYSTAL POLYMER
- Voltage Rated Dc
- 48V
- Contact Plating
- Gold
- Terminal
- PC Pin
- Circuit
- 4PDT
- Current Rating Amps
- 0.4VA AC/DC
