Volume pricing
- 1+ pcs$17.81
- 10+ pcs$16.80
- 100+ pcs$15.85
- 500+ pcs$14.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Ac
- 48V
- Center Contact Material
- PHOSPHOR BRONZE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Yayın Yılı
- 2015
- Fabrika Tedarik Süresi
- 8 Weeks
- Contact Ac Max Power Rating R Load
- 0.4VA@48VAC
- Dielectric Withstanding Voltage
- 1500VAC V
- Body Breadth
- 12.7 mm
- Contact Function
- ON-(ON)
- Bushing Thread
- Unthreaded
- Center Contact Plating
- GOLD
- Actuator Type
- Locking Lever
- Actuator Length
- 19.40mm
- Body Height
- 20.32mm
- End Contact Plating
- GOLD
- Contact Resistance
- 0.05mOhm
- Actuator Material
- Brass, Chrome Plated
- Montaj
- Through Hole, Vertical
- Çalışma Sıcaklığı
- -10°C~70°C
- Housing Material
- POLYBUTYLENE TEREPHTHALATE
- Terminal Stili
- PC Pin
- Seri
- D2
- Bushing Length
- 0.26 inch
- Parça Durumu
- Active
- Illumination
- Non-Illuminated
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Electricallife
- 50,000 Cycles
- Length Termination
- 0.138 inch
- Pcb Hole Count
- 8
- RoHS Durumu
- ROHS3 Compliant
- Insulation Resistance
- 1000000000Ohm
- Switch Function
- On-Mom
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Switch Type
- TOGGLE SWITCH
- Body Length Or Diameter
- 14.7066mm
- Contact Timing
- BREAK-BEFORE-MAKE
- Voltage Rated Dc
- 48V
- Current Rating Amps
- 0.4VA AC/DC
