Volume pricing
- 1+ pcs$18.68
- 10+ pcs$17.62
- 100+ pcs$16.62
- 500+ pcs$15.68
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 3A AC
- Çap
- 22mm
- Depth Behind Flange
- 34.60mm
- Contact Materials
- Silver (Ag)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material
- Brass, Chrome, Metal
- Yayın Yılı
- 2006
- Çalışma Sıcaklığı
- -25°C~70°C
- Max Current Rating
- 3A
- Montaj
- Panel
- Actuator Type
- Flat Key
- Orientation
- Vertical
- Voltage Rated Ac
- 250V
- Uzunluk
- 22mm
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 20mOhm
- Pozisyon Sayısı
- 3
- Özellikler
- Epoxy Sealed Terminals
- Contact Current Rating
- 3A
- Max Voltage Rating Ac
- 250V
- Panel Cutout Dimensions
- Circular - 19.00mm Dia
- ECCN Kodu
- EAR99
- Contact Style
- Non-Shorting
- Housing Material
- Polymer
- Electricallife
- 10,000 Cycles
- Terminal
- Solder
- Reach Svhc
- No SVHC
- Mechanical Life
- 30,000 Cycles
- JESD-609 Kodu
- e4
- Key Removable Positions
- 2 only
- Insulation Resistance
- 100MOhm
- Terminal Stili
- Solder Lug
- Circuit
- SPDT
- Montaj Tipi
- Panel Mount
- Parça Durumu
- Active
- Akım Değeri
- 3A
- Kurşunsuz
- Lead Free
- Index Angle
- 45 °
- Contact Currentacmax
- 3A
