Volume pricing
- 1+ pcs$5.95
- 10+ pcs$5.61
- 100+ pcs$5.29
- 500+ pcs$4.99
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Resistance
- 500000000Ohm
- Terminal Material
- BRASS
- Bushing Diameter
- 0.236 inch
- Orientation
- Right Angle
- Body Height
- 20.4724mm
- Dielectric Withstanding Voltage
- 500VAC V
- Çalışma Sıcaklığı
- -30°C~85°C
- Yayın Yılı
- 2015
- Parça Durumu
- Active
- Ambalaj
- Tray
- Actuator Material
- Polyacetal
- Pcb Hole Count
- 5
- Contact Resistance
- 0.05mOhm
- Özellikler
- Antistatic
- Color Actuatorcap
- White
- Contact Materials
- Bronze
- Contact Plating
- Gold
- Electricallife
- 50,000 Cycles
- Terminal
- PC Pin
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- RoHS Durumu
- ROHS3 Compliant
- Seri
- BB
- Voltage Rated Dc
- 28V
- Depth
- 20.5mm
- Fabrika Tedarik Süresi
- 10 Weeks
- Max Voltage Rating Dc
- 28V
- Max Current Rating
- 100mA
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Through Hole, Right Angle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 50,000 Cycles
- Terminal Stili
- PC Pin
- JESD-609 Kodu
- e4
- Current Rating Amps
- 0.4VA AC/DC
- Body Breadth
- 7.2898 mm
- Actuator Type
- Round, Button
- Uzunluk
- 8.8mm
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Ac
- 28V
- Washability
- SOLVENT
