Volume pricing
- 1+ pcs$5.18
- 10+ pcs$4.89
- 100+ pcs$4.61
- 500+ pcs$4.35
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Plating
- Gold
- Electricallife
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Voltage Rated Dc
- 28V
- Seri
- BB
- Depth
- 8mm
- Parça Durumu
- Active
- Actuator Material
- Polyacetal
- Contact Materials
- Bronze
- Contact Current Rating
- 100mA
- Reach Svhc
- No SVHC
- Insulation Resistance
- 500000000Ohm
- Terminal Material
- BRASS
- Bushing Diameter
- 0.236 inch
- Tip
- Standard
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Contact Function
- ON-(ON)
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Terminal Stili
- PC Pin
- Actuator Length
- 0.248 inch
- Current Rating Amps
- 0.4VA AC/DC
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Ac
- 28V
- Max Current Rating
- 100mA
- Max Voltage Rating Dc
- 28V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 50,000 Cycles
- Terminal
- PC Pins
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Ambalaj
- Tray
- Pcb Hole Count
- 7
- Contact Resistance
- 0.05mOhm
- Özellikler
- Antistatic
- Color Actuatorcap
- Black
- Dielectric Withstanding Voltage
- 500VAC V
- Çalışma Sıcaklığı
- -30°C~85°C
- Yayın Yılı
- 2012
- Bushing Length
- 0.106 inch
- Orientation
- Vertical
