Volume pricing
- 1+ pcs$7.62
- 10+ pcs$7.19
- 100+ pcs$6.78
- 500+ pcs$6.40
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Switch Type
- TOGGLE SWITCH
- Circuit
- DPDT
- Çalışma Sıcaklığı
- -30°C~85°C
- Actuator Length
- 6.30mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Electricallife
- 50,000 Cycles
- Body Length Or Diameter
- 8.7884mm
- Terminal Stili
- PC Pin
- Özellikler
- Epoxy Sealed Terminals
- Switch Function
- On-Mom
- Montaj Tipi
- Through Hole, Right Angle
- Body Breadth
- 8.7884 mm
- Contact Function
- (ON)-ON
- Illumination
- Non-Illuminated
- Center Contact Plating
- GOLD
- Orientation
- Right Angle
- Terminal Material
- COPPER ALLOY
- Bushing Length
- 0.106 inch
- Voltage Rated Dc
- 28V
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Insulation Resistance
- 500000000Ohm
- Ambalaj
- Tray
- Contact Resistance
- 0.05mOhm
- Parça Durumu
- Active
- Bushing Thread
- Unthreaded
- End Contact Plating
- GOLD
- Actuator Type
- Standard Round
- RoHS Durumu
- ROHS3 Compliant
- Dielectric Withstanding Voltage
- 500VAC V
- Current Rating Amps
- 0.4VA AC/DC
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Voltage Rated Ac
- 28V
- Pcb Hole Count
- 8
- Kurşunsuz Kodu
- yes
- End Contact Material
- COPPER ALLOY
- Montaj
- Through Hole
- REACH Uyumluluk Kodu
- unknown
- Fabrika Tedarik Süresi
- 10 Weeks
- Actuator Material
- Brass, Nickel Plated
- Kurşunsuz
- Contains Lead
