Specifications
- Bushing Thread
- Unthreaded
- Actuator Material
- Brass, Nickel Plated
- Terminal
- PC Pin
- JESD-609 Kodu
- e4
- Illumination
- Non-Illuminated
- Actuator Length
- 12.50mm
- Actuator Type
- Locking Lever
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Epoxy Sealed Terminals
- Seri
- B
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Length Termination
- 0.161 inch
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Kurşunsuz Kodu
- yes
- Body Height
- 37.6428mm
- Ambalaj
- Bulk
- Washability
- SOLVENT
- Dielectric Withstanding Voltage
- 500VAC V
- Fabrika Tedarik Süresi
- 8 Weeks
- Yayın Yılı
- 2010
- Solderability
- WAVE
- Contact Resistance
- 0.05mOhm
- End Contact Plating
- GOLD OVER NICKEL
- Switch Function
- On-Off-On
- Parça Durumu
- Active
- Switch Type
- TOGGLE SWITCH
- Electricallife
- 50,000 Cycles
- Body Breadth
- 8.7884 mm
- Body Length Or Diameter
- 8.7884mm
- Bushing Length
- 0.106 inch
- RoHS Durumu
- ROHS3 Compliant
- Pcb Hole Count
- 8
- Terminal Stili
- PC Pin
- Voltage Rated Ac
- 28V
- Center Contact Plating
- GOLD OVER SILVER
- Çalışma Sıcaklığı
- -30°C~85°C
- Insulation Resistance
- 500000000Ohm
- Voltage Rated Dc
- 28V
- Circuit
- DPDT
