Volume pricing
- 1+ pcs$5.56
- 10+ pcs$5.25
- 100+ pcs$4.95
- 500+ pcs$4.67
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuatorcolor
- RED
- Circuit
- DPDT
- Fabrika Tedarik Süresi
- 10 Weeks
- Switch Type
- TOGGLE SWITCH
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Electricallife
- 50,000 Cycles
- Pcb Hole Count
- 8
- Çalışma Sıcaklığı
- -30°C~85°C
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Parça Durumu
- Active
- Contact Resistance
- 0.05mOhm
- Terminal
- PC Pin
- Montaj
- Through Hole, Vertical
- Bushing Length
- 0.106 inch
- Washability
- SOLVENT
- Body Breadth
- 8.7884 mm
- Illumination
- Non-Illuminated
- Center Contact Plating
- GOLD OVER SILVER
- Length Termination
- 0.161 inch
- Seri
- B
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2006
- Switch Function
- On-On
- Body Length Or Diameter
- 8.7884mm
- Insulation Resistance
- 500000000Ohm
- Özellikler
- Red Actuator
- Voltage Rated Dc
- 28V
- Bushing Thread
- Unthreaded
- Dielectric Withstanding Voltage
- 500VAC V
- Sealing
- EPOXY
- Current Rating Amps
- 0.4VA AC/DC
- End Contact Plating
- GOLD OVER NICKEL
- Solderability
- WAVE
- Voltage Rated Ac
- 28V
- JESD-609 Kodu
- e4
- Actuator Length
- 9.40mm
- Body Height
- 29.5656mm
- Terminal Stili
- PC Pin
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Actuator Material
- Brass, Nickel Plated
