Volume pricing
- 1+ pcs$5.43
- 10+ pcs$5.12
- 100+ pcs$4.83
- 500+ pcs$4.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 0.4VA AC/DC
- Insulation Resistance
- 500000000Ohm
- Uzunluk
- 8.8mm
- Max Voltage Rating Ac
- 28V
- Reach Svhc
- No SVHC
- Kurşunsuz Kodu
- yes
- Actuator Type
- Standard Round
- Contact Current Rating
- 100mA
- Max Voltage Rating Dc
- 28V
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Actuator Length
- 10.00mm
- JESD-609 Kodu
- e4
- Pin Sayısı
- 1
- Electricallife
- 50,000 Cycles
- HTS Kodu
- 8536.50.90.65
- Circuit
- DPDT
- Switch Type
- TOGGLE SWITCH
- Seri
- B
- Body Breadth
- 8.7884 mm
- Contact Materials
- Bronze, Gold
- Pcb Hole Count
- 6
- Terminal
- Solder
- Contact Resistance
- 0.05mOhm
- Çalışma Sıcaklığı
- -30°C~85°C
- Dielectric Withstanding Voltage
- 500VAC V
- Terminal Material
- COPPER ALLOY
- Orientation
- Vertical
- Max Current Rating
- 100mA
- Özellikler
- Epoxy Sealed Terminals
- Switch Function
- On-On
- Yayın Yılı
- 2010
- Voltage Rated Dc
- 28V
- Bushing Thread
- Unthreaded
- Ambalaj
- Bulk
- Actuator Material
- Brass, Nickel Plated
- Akım Değeri
- 100mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Ac
- 28V
- Terminal Stili
- PC Pin
