Specifications
- Body Breadth
- 8.7884 mm
- Illumination
- Non-Illuminated
- Seri
- B
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Bronze, Gold
- Pcb Hole Count
- 8
- Contact Plating
- Gold
- Parça Durumu
- Active
- Contact Resistance
- 0.05mOhm
- Terminal
- PC Pin
- Montaj
- PCB, Panel, Through Hole
- Çalışma Sıcaklığı
- -30°C~85°C
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Electricallife
- 50,000 Cycles
- HTS Kodu
- 8536.50.90.65
- Circuit
- DPDT
- Fabrika Tedarik Süresi
- 5 Weeks
- Montaj Tipi
- Through Hole, Right Angle
- Depth
- 26.7mm
- Switch Type
- TOGGLE SWITCH
- Ambalaj
- Tray
- Actuator Material
- Brass, Nickel Plated
- Kurşunsuz Kodu
- yes
- Actuator Type
- Standard Round
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Current Rating
- 100mA
- Voltage Rated Ac
- 28V
- ECCN Kodu
- EAR99
- Terminal Stili
- PC Pin
- Max Voltage Rating Dc
- 28V
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- JESD-609 Kodu
- e4
- Body Height
- 13.716mm
- Actuator Length
- 10.00mm
- Kurşunsuz
- Lead Free
- Dielectric Withstanding Voltage
- 500VAC V
- Current Rating Amps
- 0.4VA AC/DC
- Orientation
- Right Angle
- Max Current Rating
- 100mA
- Terminal Material
- COPPER ALLOY
