Volume pricing
- 1+ pcs$8.65
- 10+ pcs$8.16
- 100+ pcs$7.69
- 500+ pcs$7.26
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Resistance
- 500000000Ohm
- Solderability
- WAVE
- JESD-609 Kodu
- e4
- Fabrika Tedarik Süresi
- 8 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Body Length Or Diameter
- 8.7884mm
- Length Termination
- 0.122 inch
- Actuator Length
- 12.50mm
- Circuit
- SPDT
- Actuator Material
- Brass, Nickel Plated
- Parça Durumu
- Active
- End Contact Plating
- GOLD OVER NICKEL
- Dielectric Withstanding Voltage
- 500VAC V
- Center Contact Plating
- GOLD OVER SILVER
- Terminal Stili
- PC Pin
- Özellikler
- Epoxy Sealed Terminals
- Switch Function
- On-Off-On
- Bushing Length
- 0.106 inch
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Body Breadth
- 7.2898 mm
- Pcb Hole Count
- 5
- Voltage Rated Ac
- 28V
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Montaj
- Through Hole
- Seri
- B
- Yayın Yılı
- 2010
- Voltage Rated Dc
- 28V
- Ambalaj
- Bulk
- Body Height
- 32.5628mm
- Kurşunsuz Kodu
- yes
- Electricallife
- 50,000 Cycles
- Current Rating Amps
- 0.4VA AC/DC
- Washability
- SOLVENT
- Çalışma Sıcaklığı
- -30°C~85°C
- Illumination
- Non-Illuminated
- Switch Type
- TOGGLE SWITCH
- Actuator Type
- Locking Lever
- Bushing Thread
- Unthreaded
- Montaj Tipi
- Through Hole, Right Angle
- Contact Resistance
- 0.05mOhm
