Volume pricing
- 1+ pcs$5.75
- 10+ pcs$5.43
- 100+ pcs$5.12
- 500+ pcs$4.83
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Voltage Rating Dc
- 28V
- Terminal Stili
- PC Pin
- Parça Durumu
- Active
- Pcb Hole Count
- 7
- Voltage Rated Ac
- 28V
- Switch Function
- On-Off-On
- Insulation Materials
- GLASS FILLED POLYAMIDE
- HTS Kodu
- 8536.50.90.65
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 5 Weeks
- Illumination
- Non-Illuminated
- Çalışma Sıcaklığı
- -30°C~85°C
- Switch Type
- TOGGLE SWITCH
- Actuator Type
- Standard Round
- Terminal Material
- COPPER ALLOY
- Orientation
- Vertical
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Bushing Thread
- Unthreaded
- Illumination Type
- Illuminated, Non-Illuminated
- Depth
- 8mm
- Yayın Yılı
- 2006
- Kurşunsuz Kodu
- yes
- Özellikler
- Epoxy Sealed Terminals
- Max Voltage Rating Ac
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- Switching Capacity
- 400 mW
- Pin Sayısı
- 1
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Circuit
- SPDT
- Max Current Rating
- 100mA
- Actuator Material
- Brass, Nickel Plated
- Uzunluk
- 10.56mm
- Contact Current Rating
- 100mA
- Seri
- B
- Contact Plating
- Gold
- Reach Svhc
- No SVHC
- Montaj
- Through Hole
- Insulation Resistance
- 500MOhm
- Genişlik
- 10.16mm
- Contact Materials
- Bronze, Gold
