Volume pricing
- 1+ pcs$9.04
- 10+ pcs$8.53
- 100+ pcs$8.05
- 500+ pcs$7.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 28V
- Switch Travel
- 2.50mm
- Kurşunsuz Kodu
- yes
- Depth
- 16.5mm
- Body Breadth
- 6.1722 mm
- Actuator Length
- 3.80mm
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- RoHS Durumu
- ROHS3 Compliant
- Insulation Resistance
- 500000000Ohm
- Parça Durumu
- Active
- Contact Timing
- Non-Shorting (BBM)
- Kurşunsuz
- Contains Lead
- Mechanical Life
- 50,000 Cycles
- Voltage Rated Ac
- 28V
- Body Height
- 9.8806mm
- Contact Materials
- Phosphor Bronze
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Function
- On-On-On
- Electricallife
- 50,000 Cycles
- Circuit
- SP3T
- Özellikler
- Jumper needed to achieve triple throw
- Operating Force
- 260gf
- Actuator Type
- Standard
- Terminal Stili
- PC Pin
- Montaj
- Through Hole
- Ambalaj
- Tray
- Current Rating Amps
- 0.4VA AC/DC
- Fabrika Tedarik Süresi
- 18 Weeks
- Max Voltage Rating Dc
- 28V
- Sealing
- EPOXY
- Terminal
- PC Pin
- Contact Style
- Non-Shorting
- Max Current Rating
- 100mA
- Uzunluk
- 9.8mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Dielectric Withstanding Voltage
- 500VAC V
- Max Voltage Rating Ac
- 28V
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Yayın Yılı
- 2010
- Seri
- AS
